EXHIBIT 11-A



Draft Text

2005 Annual Report

Monterey Peninsula Water Management District



Aquifer Storage and Recovery Benefits Community and Environment



Aquifer storage and recovery (ASR) entails diverting excess Winter/Spring flows from the Carmel River Basin, in compliance with State and federal requirements, and injecting the treated water into the Seaside Groundwater Basin for later recovery in dry periods.  Water is extracted and used when and where it is plentiful; impacts to the river are reduced when it is most vulnerable.



The District owns and operates the full-scale “Santa Margarita Test Injection Well” on the former Fort Ord.  Since 1998, the District in cooperation with California American Water (Cal-Am), has injected approximately 1,600 acre-feet (AF) of excess winter flow from the Carmel River into the Seaside Basin.  About 1,100 AF have been recovered and delivered to the community via the Cal-Am system as part of the test program.



In 2005, MPWMD staff continued short-term testing, with emphasis on water quality.  About 350 AF were injected into the Seaside Basin.  Staff also pursued a long-term Phase I ASR Project consisting of a second injection well at the existing test site, electrical and disinfection equipment, and a replacement connector pipeline. The project entails a maximum diversion of 2,400 AFY from the Carmel River, and an average yield of about 1,050 AFY from the Seaside Basin.  Phase I is complementary to other larger, long-term water augmentation projects.



In 2005, MPWMD neared completion of an Environmental Impact Report (EIR) and Environmental Assessment (EA) of the MPWMD Phase I ASR Project.  The EIR/EA also evaluates a temporary Cal-Am pipeline planned for 2006 to increase Cal-Am system reliability and to maximize the Phase I project performance.  Progress was also made on water rights for the ASR Project.  The State Water Resources Control Board (SWRCB) noticed the District’s water rights applications and District staff responded to two protests.  A final decision would occur after the EIR/EA is certified.



District staff continued to negotiate with Cal-Am on a Management and Operations Agreement on ASR testing, mutual aid, cost-sharing, water rights and other issues.  The Board considered draft versions in mid-2005, but did not approve a final version until early 2006.



Financial Update



Total revenues received in FY 2004-05 was $3,935,593 while expenditures totaled $4,266,594.  The difference of $331,001 was funded from general operating reserves set aside in previous years to fund projects such as those the District is currently pursuing.  As of June 30, 2005, a balance of $2,223,274 remained in the general operating reserves account.



The adopted Budget for FY 2005-06 anticipates revenues of $4,464,000 and expenditures of $4,650,800 combined with the use of an additional $186,800 in general operating reserves.



The FY 2005-06 budget was prepared using a series of strategies developed by the staff and adopted by the Board in 2004 ending the use of general operating reserves to balance the budget.  Included in the budget was a 1.2% increase to the user fee to provide funding for the completion of Phase I of the District’s Aquifer Storage and Recovery Project.  The budget was also expanded to a program and performance based budget.





Steelhead Rescue and Rearing Season



During 2005 District staff rescued a total of 20,805 steelhead from drying reaches of the Carmel River including 20,289 young-of-the-year, 119 yearlings, one smolt and 42 mortalities.   All of the fish rescued were transported and taken to the Sleepy Hollow Steelhead Rearing Facility (Facility) where they were first quarantined to control potential parasitic infestations and bacterial infections.  A total of 24,630 fish were brought to the Facility through September 2005, including a supplement of 3,825 fish from rescues conducted by the Carmel River Steelhead Association.  Of this total, 24,457 fish were stocked in the tanks and rearing channel.  The overall survival rate of fish held at the Facility in 2005 was 57%, or 13,911 fish, which was a favorable result compared to survival in natural conditions and showed that the combination of the cooling tower, quarantine protocol, feeding regime, and nature-like habitat in the rearing channel was successful in rearing wild-caught juvenile steelhead.  All surviving fish were in excellent physical condition, and many had transformed into smolts.



Year 2005 Accomplishments and Milestones



Water Supply



Ø      Updated comprehensive matrix on water supply concepts that could meet community needs.  Concepts included three desalination plants, aquifer storage and recovery (ASR) in the Seaside Basin, and two types of reclaimed water projects.

Ø      Neared completion of Environmental Impact Report/Assessment (EIR/EA) of proposed Phase I ASR Project as well as alternatives.  The project will help reduce impacts to the Carmel River and replenish the overdrawn Seaside Basin.

Ø      Obtained temporary water rights and diverted 350 AF of Carmel River water into the Seaside Basin; conducted water quality tests to quantify beneficial effect on Basin.

Ø      Continued efforts on Seaside Basin Groundwater Management Plan, including completion of a major technical study assessing the basin status and recommending solutions.



Environmental Protection



Ø      Maintained flow monitoring stations at 4 sites on the Carmel River and 11 sites on creeks to better assess surface water resources within the District.

Ø      Counted 328 adult steelhead at the San Clemente Dam fish ladder to assess the winter run.

Ø      Collected surface water quality data from 3 Carmel River sites and water temperature data from 8 locations, focused on habitat conditions for rearing steelhead.

Ø      Collected groundwater level data at 70 wells and groundwater quality data at 25 wells from the District’s monitor well networks in the Carmel River and Seaside Basins.

Ø      Conducted benthic macroinvertebrate sampling at 5 locations as an indicator of habitat quality for all aquatic Carmel River biota.

Ø      Conducted steelhead juvenile population surveys throughout the length of the Carmel River.



Conservation/Permitting



Ø      Approved 322 rebate applications for a total of $41,607 resulting in annual water savings of 6.862 acre-feet.

Ø      Issued 1,351 water permits and performed 1,849 inspections resulting in annual water savings of 29.210 acre-feet.

Ø      Gave presentation on water conservation to the Fisherman’s Flats Homeowners Association in Monterey.  Free showerheads and moisture sensors were provided to approximately 30 attendees.

Ø      Attended a meeting of the California Urban Water Conservation Council (CUWCC) steering committee.  The CUWCC meetings provide a forum for discussion and demonstration of the latest water conservation techniques and technology.

Ø      Manned a booth at the Farmer’s Market in downtown Monterey.  The District collaborated with the City of Monterey and other local public agencies to provide demonstrations on equipment and to hand out information.  Among the items shown was a model ultra-low flush toilet and examples of the waterless urinals and pressure reducing valves.

Ø      Participated in the Water Awareness Committee of Monterey County’s 1st Annual Xeriscape Design Awards at the Monterey County Fair.  Staff judged the garden displays in the horticultural center for promotion of the Water Awareness Committee’s Retire Your Turf campaign.



MPWMD Events Highlight Water Supply Options



Following the MPWMD Board’s directive to explore opportunities to collaborate on regional water supplies, the District sponsored a Town Hall Meeting on potential water supply solutions on August 25, 2005, which was attended by over 100 people.  Project proponents set up displays, made presentations and fielded questions from the audience.  The following entities participated in the event:



Ø      California American Water

Ø      Marina Coast Water District

Ø      Monterey County Water Resources Agency

Ø      Monterey Peninsula Water Management District

Ø      Monterey Regional Water Pollution Control Agency

Ø      Pajaro/Sunny Mesa Community Services District



The above participants also worked closely with MPWMD staff to update the Comparative Matrix of Water Supply Options for a focused discussion at the September 8, 2005 Strategic Planning Workshop.  The 2005 Matrix features revised project description, cost and timeline information as well as one new project for review.  Visit the MPWMD website for detailed information.



District staff continues to coordinate with several agencies on regional water supply opportunities. The District General Manager participates in Monterey County-led meetings of water district and city/county representatives regarding a potential governance structure for a publicly-owned regional project.  Updates on this process are provided to the Board at each regular meeting.



2005 Board of Directors

Larry Foy, Chair

Division 5

Kristi Markey, Vice-Chair

Division 3

Alvin Edwards

Division 1

Judi Lehman

Division 2

Michelle Knight

Division 4

David Pendergrass

Mayoral Representative

David Potter

Monterey County

Board of Supervisors

Representative



 Staff Contact Information

General Information

658-5600



Water Permit Office

658-5601



David A. Berger

General Manager/Board Secretary

658-5650

Andrew Bell

Planning & Engineering Manager/District Engineer

658-5620

Rick Dickhaut

Administrative Services Manager/CFO/Treasurer

658-5614

David Laredo

General Counsel

658-5650

Joseph Oliver

Water Resources Manager

658-5640

Stephanie Pintar

Water Demand Manager

658-5630

Henrietta Stern

Project Manager

658-5621



We Want To Hear From You



If you found the information in this report useful or have questions about water supply, conservation or other topics in this report, please contact Henrietta Stern at henri@mpwmd.dst.ca.us or at 658-5621
